*Discontinued* Record – HA8-LP – Low Profile Swing Door Operator – PULL Arm – Right Hand – Antique Bronze (39″ to 51″) For Single Doors

ENT-WL-108The Ditec HA8-LP low-energy operator has the same power and durability of the standard profile, but with a smaller header for applications where clearance is limited. The low-profile is available as surface applied, and can be found in hospitals, retail stores, schools & universities, airports, convention centers, casinos, industrial buildings and offices.Antique Bronze FinishAvailable in 39″, 45″ or 51″ sizes (Select Below)Non-Handed operatorOpens easily during manual operation Quiet Operation Permanent lubrication means maintenance freeEasy installation (average install time is 1-1/2 hours) UL325/UL10C ApplicationSingle DoorsHeader Profile Dimensions4 1/8″ x 5 1/8″Motor1/8 HPManual Opening/Closing ForceAdjustable 5 to 30 lbs.Push RevealUp to 14″Pull RevealUp to 5″Total Weight with 39″ Header44 lbsHandingPull Arm Right HandDrive Train Gear BoxAluminum-Alloy GearboxControl BoxSingle HA-8 w/Data, 24 VDC, 3 AMPOperating Voltage (Standard)115VACGear GreaseHigh Wear ProtectionBearingsHD SealedMotor1/8th HPManual Opening/Closing ForceAdjustable 5 to 30 lbsArm Connection1” Solid Spline SpindleAdjustable StopYesOperator SwitchOn-Off-Hold OpenAdjustable Spring TensionYesMechanical ClutchStandardPush or Pull ApplicationPullEasy Manual OperationYesSurface MountingYesSide LoadingYesPush RevealUp to 14”Pull RevealUp to 5”Electric Strike Power Yes  24 VDCFire Door CompatibilityUL10C ApprovedCircuit Protection3 amp FuseTotal Weight w/ 39″ Header44 lbsMeets ANSI 156.19 Low Energy Yes Watch Complete Installation Video HereSpec SheetInstallation Manual
