Camden CV-110SPK Standalone PROX Reader & Keypad – 2000 Users – Vandal & Weather Resistant IP68 – 12 VDC

Camden CV-110SPK is a slim-line single door multi-function standalone keypad that supports up to 2000 users with a Card, 4 digit PIN, or a Card + PIN option. The electronics are fully potted so the unit is waterproof and conforms to IP68. The built-in prox. card reader supports 125KHZ EM cards. The CV-110SPK offers a 26 bit Wiegand input and output allows the unit to also operate as a dual credential (prox. reader and keypad) access control system device.Up to 2,000 users – cards or tagsBacklit KeysZinc Alloy electroplated anti-vandal constructionWeatherproof, IP68 ratingFully programming from keypadAdjustable door output time, alarm time, door open timeLow power consumptionAnti-temper, built-in light dependent resistorLook output short circuit protection8 bit burst (keypad), 26 bit (reader) Wiegand output, for integration with access control systems3 year warrantySpecifications:Voltage:12 VDCUsers:2,000Reader Format:EM FormatCurrent Draw:60 mAContact Type:(1) Form ‘C’Contact Rating:3 A @ 30 VDCAlarm Output:20 mAProtection:IP68 RatedDoor Delay Time:0 to 99 SecondsAlarm Time:0 to 3 minutesWiegand Interface:8 bit burst for PIN codes26 bit for cardsTemp Range:-49°F to 140°F(-45°C to 60°C)Dimensions:5-7/8”H x 1-3/4”W x 1”D(150mm x 44mm x 25mm)Spec SheetsSpec SheetManualsUser Manual
