Camden CM-60/4 – Round Push Plate Switch – w/ Push to Open Sign – 6″

CM-40, CM-41 and CM-60 Series ‘All-Active’ push plate switches are heavy-duty, ADA-compliant door controls. Faceplates are stainless steel or solid brass, and the assembly is designed for easy installation. The CM-41 4-1/2″ square stainless steel backplate is large enough to dress-up (cover) a poorly installed electrical box. It will also fit perfectly on most 4-1/2″ surface boxes.4 stud switch design and rubber dampers for quieter operationDurable stainless steel or brass constructionAll-Active design requires minimal actuation forceLarge variety of graphics optionsAvailable in a range of architectural finishes3 year warranty with ‘2 for 1’ replacementSpecifications:Voltage:12/24V AC/DCSwitch Type:MomentaryContact Type:SPDT Form ‘C’Contact Rating:15 A @ 30 VDCMounting:CM-40/41: Single GangCM-60: Single or Double Gang or 4 x 4Std. Finish:US32 / 630Dimensions:CM-40: 4-1/2″ x 1-3/4″(114mm x 44mm)CM-45: 4-1/2″ x 4-1/2″ x 1-3/4″(114mm x 114mm x 44mm)CM-60: 6″ x 1-1/8″(152mm x 28.6mm)Spec SheetsSpec SheetReference GuidesPush Plate Switch Cross Reference Push Button Switch Cross ReferenceOBC Compliant Push Plate Switches_R2
