Alarm Lock Trilogy – DL1200ET – Narrow Stile Keypad Exit Lever Lock – 26D – Satin Chrome – Grade 1

The Trilogy Narrow Stile Keypad Exit Lever Lock models support Arrow, DCI, Von Duprin and Dorma panic exit bars. Get field-proven Trilogy® keyless access lock convenience anywhere there’s a Narrow Stile compatible door. Important Note: Tailpiece is sold separately and is required for most installations (compatibility table below)—TailpieceCompatible DevicesALL-TP-1691Arrow S1200/1250, Von Duprin 22 & Dorma 5300, DCI 1200/1300 Panic DevicesALL-TP-1693Corbin ED8200 Panic DeviceALL-TP-1694Von Duprin 33 LH (RHR) Devices only SpecificationsLOCK FUNCTIONNarrow Stile Keypad Exit Lever LockDOOR THICKNESSOnly Stile thickness 1 ¾”BACKSET31/32”,1 1/8’ and 1-1/2”HANDINGNon-handed; fully field-reversibleLEVER TRIMAluminum door retrofit Arrow, DCI, Von Duprin and Dorma panic exit barsPOWERLong-life, battery-operated for 100,000 and 80,000 cycles respectively, typical on 2 lithium 3V batteries, supplied; low battery alertCYLINDER1-1/4” supplied (Supports 1-1/8, 1-1/4, and 1-3/8”)PROGRAMMABLEYesUSER CODESkeypad supports 100 users, fingertip/keypad programmableWEATHERPROOF-31˚ to +151˚F (-35˚ to +66˚C)FINISHUS26D Satin Chrome Return Policy: We accept returns on unopened products up to 30 days after the date of purchase. We do not accept opened/damaged/defective goods. To return affected items please contact Alarm Lock directly at 1-800-645-9440 or visit their support page here Downloads:Brochure
